Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EET-HC2W271JACAP ALUM 270UF 20% 450V SNAP TH |
4,223 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 270 µF | ±20% | 450 V | 675mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.19 A @ 120 Hz | 1.666 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
EET-HC2W271KFCAP ALUM 270UF 20% 450V SNAP TH |
2,515 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 270 µF | ±20% | 450 V | 675mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.19 A @ 120 Hz | 1.666 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
EET-HC2W271KACAP ALUM 270UF 20% 450V SNAP TH |
2,906 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 270 µF | ±20% | 450 V | 675mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.19 A @ 120 Hz | 1.666 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
EET-HC2W271LACAP ALUM 270UF 20% 450V SNAP TH |
1,986 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 270 µF | ±20% | 450 V | 675mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.19 A @ 120 Hz | 1.666 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
EET-HC2W331KFCAP ALUM 330UF 20% 450V SNAP TH |
4,215 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 330 µF | ±20% | 450 V | 553mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.38 A @ 120 Hz | 1.932 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
EET-HC2W331KACAP ALUM 330UF 20% 450V SNAP TH |
2,114 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 330 µF | ±20% | 450 V | 553mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.38 A @ 120 Hz | 1.932 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
|
EET-HC2W331LACAP ALUM 330UF 20% 450V SNAP TH |
4,926 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 330 µF | ±20% | 450 V | 553mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.38 A @ 120 Hz | 1.932 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
EET-HC2W391KFCAP ALUM 390UF 20% 450V SNAP TH |
1,288 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 390 µF | ±20% | 450 V | 468mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.55 A @ 120 Hz | 2.17 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
EET-HC2W391KACAP ALUM 390UF 20% 450V SNAP TH |
2,664 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 390 µF | ±20% | 450 V | 468mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.55 A @ 120 Hz | 2.17 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
EET-HC2W391LACAP ALUM 390UF 20% 450V SNAP TH |
4,458 | - |
|
Datasheet | TS-HC | Bulk | Obsolete | 390 µF | ±20% | 450 V | 468mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.55 A @ 120 Hz | 2.17 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole |
