Chip Resistor - Surface Mount
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Resistance | Tolerance | Power (Watts) | Composition | Features | Temperature Coefficient | Operating Temperature | Supplier Device Package | Ratings | Size / Dimension | Height - Seated (Max) | Number of Terminations | Failure Rate |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
KDV12FR150ETRES 0.15 OHM 1% 1/2W 1206 |
6,181 | - |
|
Datasheet | KDV | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 150 mOhms | ±1% | 0.5W, 1/2W | Metal Film | Current Sense | ±50ppm/°C | -55°C ~ 155°C | - | 1206 | 0.133" L x 0.063" W (3.10mm x 1.60mm) | 0.026" (0.65mm) | 2 | - |
|
LVT12R0100FERRES 0.01 OHM 1% 1W 1206 |
146,246 | - |
|
Datasheet | LVT | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 10 mOhms | ±1% | 1W | Metal Element | Current Sense | ±75ppm/°C | -55°C ~ 155°C | - | 1206 | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.026" (0.65mm) | 2 | - |
|
|
LVT12R0050FERRES 0.005 OHM 1% 1W 1206 |
192,477 | - |
|
Datasheet | LVT | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 5 mOhms | ±1% | 1W | Metal Element | Current Sense | ±75ppm/°C | -55°C ~ 155°C | - | 1206 | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.026" (0.65mm) | 2 | - |
|
PCS2512DR0500ET2W 0.050 OHMS 0.5% 2512 |
16,904 | - |
|
Datasheet | PCS | 2512 (6432 Metric) | Tape & Reel (TR) | Active | 50 mOhms | ±0.5% | 2W | Metal Film | Current Sense | ±50ppm/°C | -55°C ~ 170°C | - | 2512 | 0.250" L x 0.120" W (6.35mm x 3.05mm) | 0.026" (0.66mm) | 2 | - |
|
MCS1632R010FERRES 0.01 OHM 1% 1W 1206 |
1,043,921 | - |
|
Datasheet | MCS | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 10 mOhms | ±1% | 1W | Metal Element | Current Sense, Flame Retardant Coating, Safety | ±50ppm/°C | -55°C ~ 150°C | - | 1632 | 0.130" L x 0.067" W (3.30mm x 1.70mm) | 0.033" (0.85mm) | 2 | - |
|
KDV04FR100ETRES 0.1 OHM 1% 1/8W 0402 |
21,622 | - |
|
Datasheet | KDV | 0402 (1005 Metric) | Tape & Reel (TR) | Active | 100 mOhms | ±1% | 0.125W, 1/8W | Metal Film | Current Sense | ±100ppm/°C | -55°C ~ 155°C | - | 0402 | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.016" (0.40mm) | 2 | - |
|
|
LVT12R0200FERRES 0.02 OHM 1% 1W 1206 |
215,560 | - |
|
Datasheet | LVT | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 20 mOhms | ±1% | 1W | Metal Element | Current Sense | ±50ppm/°C | -55°C ~ 155°C | - | 1206 | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.026" (0.65mm) | 2 | - |
|
|
MCS3264R005FERRES 0.005 OHM 1% 2W 2512 |
509,649 | - |
|
Datasheet | MCS | 2512 (6432 Metric) | Tape & Reel (TR) | Active | 5 mOhms | ±1% | 2W | Metal Element | Current Sense, Flame Retardant Coating, Safety | ±100ppm/°C | -55°C ~ 150°C | - | 3264 | 0.252" L x 0.126" W (6.40mm x 3.20mm) | 0.024" (0.60mm) | 2 | - |
|
|
MCS3264R020FERRES 0.02 OHM 1% 2W 2512 |
383,654 | - |
|
Datasheet | MCS | 2512 (6432 Metric) | Tape & Reel (TR) | Active | 20 mOhms | ±1% | 2W | Metal Element | Current Sense, Flame Retardant Coating, Safety | ±50ppm/°C | -55°C ~ 150°C | - | 3264 | 0.252" L x 0.126" W (6.40mm x 3.20mm) | 0.024" (0.60mm) | 2 | - |
|
FCSL20R010FERRES 0.01 OHM 1% 1W 0805 |
26,411 |
1+：$0.36800 10+：$0.23360 25+：$0.19808 50+：$0.17584 100+：$0.15680 250+：$0.13597 500+：$0.12288 1000+：$0.11177 |
|
Datasheet | FCSL | Wide 0805 (2012 Metric), 0508 | Tape & Reel (TR) | Active | 10 mOhms | ±1% | 1W | Metal Foil | Current Sense, Moisture Resistant | ±50ppm/°C | -55°C ~ 155°C | - | 2012 | 0.049" L x 0.079" W (1.25mm x 2.00mm) | 0.031" (0.80mm) | 2 | - |
