RF Switches
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R516731100IC RF SWITCH |
1 |
1+：$274.60800 10+：$237.27920 25+：$227.96160 |
|
Datasheet | * | - | Strip | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R516733100IC RF SWITCH SPDT 26.5GHZ MODULE |
4,194 | - |
|
Datasheet | - | Module | Strip | Active | General Purpose | - | SPDT | 0Hz ~ 26.5GHz | 40dB (min) | 1.6dB (max) | 26.5GHz | - | - | - | 50Ohm | 20.5V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
R585452300IC RF SWITCH SPDT 18GHZ |
4,241 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R577833105IC RF SWITCH DPDT 40GHZ |
4,176 | - |
|
Datasheet | DPDT | Module | Bulk | Active | General Purpose | - | DPDT | 0Hz ~ 40GHz | 50dB (min) | 0.8dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573883600IC RF SWITCH SP6T 40GHZ |
2,345 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573883400IC RF SWITCH SP4T 40GHZ |
1,841 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574F11601IC RF SWITCH SP6T 26.5GHZ |
4,760 | - |
|
Datasheet | SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 60dB (min) | 0.3dB (max) | 26.5GHz | - | - | - | 50Ohm | 5V | -25°C ~ 75°C | - | - | - | - |
|
R570412100IC RF SWITCH SPDT 18GHZ MODULE |
3,191 | - |
|
Datasheet | - | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.35dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
R570412000LPIC RF SWITCH SPDT 18GHZ MODULE |
1,509 | - |
|
Datasheet | - | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.35dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -25°C ~ 70°C | - | - | - | Module |
|
R570013005IC RF SWITCH SPDT 3GHZ |
4,020 | - |
|
Datasheet | - | Module | Box | Active | General Purpose | - | SPDT | 0Hz ~ 3GHz | 75dB | 0.25dB | 3GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
