RF Switches
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R573J23615IC RF SWITCH SP6T 50GHZ |
2,861 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
R574F11801IC RF SWITCH SP8T 26.5GHZ |
3,543 | - |
|
Datasheet | SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 26.5GHz | 55dB (min) | 1.1dB (max) | 26.5GHz | - | - | - | 50Ohm | 5V | -25°C ~ 75°C | - | - | - | - |
|
|
FMSW2034PIN DIODE SWITCH SMA SP12T 20GHZ |
4,130 | - |
|
Datasheet | - | - | Bag | Active | General Purpose | Absorptive | SP12T | 100MHz ~ 20GHz | 65dB (min) | 6dB | 20GHz | - | - | - | 50Ohm | -12V, 5V | -55°C ~ 85°C | - | - | Chassis Mount | - |
|
R574482025IC RF SWITCH SP10T 18GHZ |
1,023 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R594873617RIC RF SWITCH SP6T 40GHZ |
3,724 | - |
|
Datasheet | PLATINUM | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 60dB (min) | 0.9dB (max) | 40GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
R574402225IC RF SWITCH SP12T 12.4GHZ |
2,553 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SP12T | 0Hz ~ 12.4GHz | 60dB (min) | 0.7dB (max) | 12.4GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574402285IC RF SWITCH SP12T 12.4GHZ |
4,591 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SP12T | 0Hz ~ 12.4GHz | 60dB (min) | 0.7dB (max) | 12.4GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574403285IC RF SWITCH SP12T 12.4GHZ |
2,299 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP12T | 0Hz ~ 12.4GHz | 60dB (min) | 0.6dB (max) | 12.4GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573J23425IC RF SWITCH SP4T 50GHZ |
4,721 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
|
FMSW5001HIGH ISO SWITCH SMA 0MHZ-20GHZ |
3,708 | - |
|
Datasheet | - | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R574F13085IC RF SWITCH SP10T 22GHZ |
3,379 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 22GHz | 55dB (min) | 0.8dB (max) | 22GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574493085IC RF SWITCH SP10T 18GHZ |
4,770 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574493025IC RF SWITCH SP10T 18GHZ |
4,712 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574492025IC RF SWITCH SP10T 18GHZ |
4,253 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574102025IC RF SWITCH SP10T 8GHZ |
2,128 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 8GHz | 70dB (min) | 0.5dB (max) | 8GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6410EM RELAY SWITCH 20 GHZ 28 V SMA |
4,882 | - |
|
Datasheet | - | - | Bag | Active | General Purpose | - | SP10T | 0Hz ~ 20GHz | 80dB | 0.25dB | 20GHz | - | - | - | 50Ohm | 26V ~ 30V | -25°C ~ 70°C | - | - | Chassis Mount | - |
|
R574J03400IC RF SWITCH SP6T 50GHZ |
1,028 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
R574J03410IC RF SWITCH SP4T 50GHZ |
1,495 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
R574J02400IC RF SWITCH SP4T 50GHZ |
3,390 | - |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -25°C ~ 70°C | - | - | - | - |
|
R573J13685IC RF SWITCH SP6T 50GHZ |
3,467 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
