DIP Switches
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Number of Positions | Current Rating (Amps) | Voltage Rating | Actuator Type | Actuator Level | Contact Material | Contact Finish | Height Above Board | Mounting Type | Termination Style | Pitch | Washable | Features | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
7813J-1-051ESWITCH ROTARY DIP SPDT 0.1A 16V |
1,885 | - |
|
Datasheet | 7813 | Tape & Reel (TR) | Active | SPDT | 2 | 100mA | 16VAC/DC | Rotary for Tool | Flush, Recessed | - | - | 0.087" (2.20mm) | Surface Mount | J Lead | - | No | - | -55°C ~ 125°C |
|
7829S-1-051SWITCH ROTARY DIP SPDT 0.1A 16V |
1,285 | - |
|
Datasheet | 7829 | Tube | Active | SPDT | 2 | 100mA | 16VAC/DC | Rotary for Tool | Raised | - | - | 0.330" (8.38mm) | Through Hole, Right Angle | PC Pin | - | Yes | - | -55°C ~ 125°C |
|
7813S-1-051ESWITCH ROTARY DIP SPDT 0.1A 16V |
4,258 | - |
|
Datasheet | 7813 | Tape & Reel (TR) | Active | SPDT | 2 | 100mA | 16VAC/DC | Rotary for Tool | Flush, Recessed | - | - | 0.211" (5.35mm) | Surface Mount, Right Angle | J Lead | - | No | - | -55°C ~ 125°C |
|
|
7814H-1-023SWITCH ROTARY DIP SPDT 0.1A 16V |
3,327 | - |
|
Datasheet | 7814 | Tube | Active | SPDT | 2 | 100mA | 16VAC/DC | Rotary for Tool | Flush, Recessed | - | - | 0.100" (2.54mm) | Through Hole | PC Pin | - | No | - | -55°C ~ 125°C |
|
|
7814H-1-051SWITCH ROTARY DIP SPDT 0.1A 16V |
4,466 | - |
|
Datasheet | 7814 | Tube | Active | SPDT | 2 | 100mA | 16VAC/DC | Rotary for Tool | Flush, Recessed | - | - | 0.100" (2.54mm) | Through Hole | PC Pin | - | No | - | -55°C ~ 125°C |
|
7814Z-1-051ESWITCH ROTARY DIP SPDT 0.1A 16V |
3,353 | - |
|
Datasheet | 7814 | Tape & Reel (TR) | Active | SPDT | 2 | 100mA | 16VAC/DC | Rotary for Tool | Flush, Recessed | - | - | 0.226" (5.74mm) | Surface Mount, Right Angle | J Lead | - | No | - | -55°C ~ 125°C |
