RF Switches
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R574012300IC RF SWITCH SP3T 3GHZ |
1,003 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574102400IC RF SWITCH SP4T 12.4GHZ |
2,804 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 12.4GHz | 60dB (min) | 0.5dB (max) | 12.4GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574103400IC RF SWITCH SP4T 12.4GHZ |
2,011 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 12.4GHz | 60dB (min) | 0.5dB (max) | 12.4GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574F02325IC RF SWITCH SP3T 26.5GHZ |
4,642 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574412620IC RF SWITCH SP6T 18GHZ |
4,178 | - |
|
Datasheet | SPnT | Module | Bulk | Obsolete | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574413620IC RF SWITCH SP6T 18GHZ |
1,963 | - |
|
Datasheet | SPnT | Module | Bulk | Obsolete | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573492525IC RF SWITCH SP5T 18GHZ |
4,282 | - |
|
Datasheet | RAMSES | Module | Bulk | Active | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R573493585IC RF SWITCH SP5T 18GHZ |
2,520 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573493525IC RF SWITCH SP5T 18GHZ |
2,758 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6423EM RELAY SWITCH 26.5 GHZ 12 V SM |
1,229 | - |
|
Datasheet | - | - | Bag | Active | General Purpose | - | SP4T | 0Hz ~ 26.5GHz | 80dB | 0.40dB | 26.5GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 70°C | - | - | Chassis Mount | - |
|
R573933600IC RF SWITCH SP6T 2.5GHZ |
4,870 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 2.5GHz | 70dB (min) | 0.3dB (max) | 2.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
|
FMSW6354EM RELAY SWITCH 18 GHZ 12 V SMA |
3,666 | - |
|
Datasheet | - | - | Bag | Active | General Purpose | Absorptive | SPDT | 0Hz ~ 18GHz | 85dB | 0.15dB | 18GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 70°C | - | - | Chassis Mount | - |
|
|
FMSW6296EM RELAY SWITCH 22 GHZ 28 V SMA |
2,719 | - |
|
Datasheet | - | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R574F03610IC RF SWITCH SP6T 26.5GHZ |
1,596 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574F03600IC RF SWITCH SP6T 26.5GHZ |
2,824 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6176EM RELAY SWITCH 12.4 GHZ 12 V TY |
4,332 | - |
|
Datasheet | - | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
R573403800IC RF SWITCH SP8T 18GHZ |
4,189 | - |
|
Datasheet | SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R573403810IC RF SWITCH SP8T 18GHZ |
2,949 | - |
|
Datasheet | SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573933420IC RF SWITCH SP4T 2.5GHZ |
1,180 | - |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 2.5GHz | 70dB (min) | 0.3dB (max) | 2.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
|
FMSW6434EM RELAY SWITCH 12 GHZ 12 V TYPE |
4,053 | - |
|
Datasheet | - | - | Bag | Active | General Purpose | - | SP4T | 0Hz ~ 12GHz | 90dB | 0.3dB | 12GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 65°C | - | - | Chassis Mount | - |
