Power Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
186D12PWR XFMR LAMINATED 31.5VA CHAS |
4,263 | - |
|
Datasheet | 186 | Box | Active | Laminated Core | 115V, 230V | 12.6V | 2.5A | Dual | Single | Yes | 31.5VA | Chassis Mount | Solder, Quick Connect | 82.55mm L x 52.20mm W | 49.02mm | 2000Vrms | 1.4 lbs (635 g) |
|
183F12PWR XFMR LAMINATED 5VA TH |
3,850 | - |
|
Datasheet | 183 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 800mA, Series 400mA | Dual | Dual | No | 5VA | Through Hole | PC Pin | 41.28mm L x 36.50mm W | 34.93mm | 4000Vrms | 0.37 lb (167.83 g) |
|
187C10PWR XFMR LAMINATED 12VA CHAS MT |
1,998 | - |
|
Datasheet | 187 | Box | Active | Laminated Core | 115V | 10V | 1.2A | Single | Single | Yes | 12VA | Chassis Mount | Solder, Quick Connect | 71.37mm L x 43.82mm W | 41.15mm | 2000Vrms | 0.68 lb (308.44 g) |
|
|
187C12PWR XFMR LAMINATED 12.6VA CHAS |
2,702 | - |
|
Datasheet | 187 | Box | Active | Laminated Core | 115V | 12.6V | 1A | Single | Single | Yes | 12.6VA | Chassis Mount | Solder, Quick Connect | 71.37mm L x 43.82mm W | 41.15mm | 2000Vrms | 0.75 lb (340.19 g) |
|
166G20PWR XFMR LAMINATED 10VA CHAS MT |
4,324 | - |
|
Datasheet | 166 | Bulk | Active | Laminated Core | 115V | 20V | 500mA | Single | Single | Yes | 10VA | Chassis Mount | Wire Leads | 71.37mm L x 41.40mm W | 42.93mm | 2000Vrms | 0.7 lb (317.51 g) |
|
|
166G14PWR XFMR LAMINATED 7VA CHAS MT |
1,297 | - |
|
Datasheet | 166 | Bulk | Active | Laminated Core | 115V | 14V | 500mA | Single | Single | Yes | 7VA | Chassis Mount | Wire Leads | 71.37mm L x 38.10mm W | 42.93mm | 2000Vrms | 0.7 lb (317.51 g) |
|
162F120PWR XFMR LAMINATED 6VA TH |
4,405 | - |
|
Datasheet | 162 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 60V, Series 120V | Parallel 100mA, Series 50mA | Dual | Dual | No | 6VA | Through Hole | PC Pin | 41.28mm L x 33.32mm W | 33.32mm | 2500Vrms | 0.44 lb (199.58 g) |
|
|
162F12PWR XFMR LAMINATED 6VA TH |
1,447 | - |
|
Datasheet | 162 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 1A, Series 500mA | Dual | Dual | No | 6VA | Through Hole | PC Pin | 41.28mm L x 33.32mm W | 33.32mm | 2500Vrms | 0.44 lb (199.58 g) |
|
160G56PWR XFMR LAMINATED 10VA TH |
4,552 | - |
|
Datasheet | 160 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 28V, Series 56V | Parallel 360mA, Series 180mA | Dual | Single, Multiple Taps | No | 10VA | Through Hole | PC Pin | 49.28mm L x 36.58mm W | 42.93mm | 2000Vrms | 0.59 lb (267.62 g) |
|
|
166E12PWR XFMR LAMINATED 1.8VA CHAS MT |
2,878 | - |
|
Datasheet | 166 | Bulk | Active | Laminated Core | 115V | 12V | 150mA | Single | Single | Yes | 1.8VA | Chassis Mount | Wire Leads | 52.32mm L x 35.05mm W | 30.23mm | 2000Vrms | 0.3 lb (136.08 g) |
